Feature and usage:
1. It is new developed which small footprint, easy operation without experience.
2. Save glue, glue only the equivalent of the amount of hand-gluing 1/3.
3. provincial labor, machine maximum speed of 56 m / min, the efficiency is 3-4 times the hand-operated.
4. Stick tidily and no shape even,use unique technology to grinding edge for better gluing effect.
| NO. | Model | 1500 | 1800 | 2000 |
|---|---|---|---|---|
| 1 | Power supply | 3-380VAC | 3-380VAC | 3-380VAC |
| 2 | Frequency - HZ | 50/60 | 50/60 | 50/60 |
| 3 | Power | 3.2KW | 3.2KW | 3.2KW |
| 4 | Electric current | 6.3A | 7.0A | 7.0A |
| 5 | Weight | 1.7ton | 1.9ton | 2.0ton |
| 6 | Dimensions | 2200*1900*1300mm | 2200*2400*1300mm | 2200*2600*1300mm |
| 7 | Gluing maximum size | 1500*1100mm | 1800*1100mm | 1800*1100mm |
| 8 | Gluing minimum size | 200*260mm | 200*260mm | 200*260mm |
