• Corrugated Cardboard Production Line

LUM-C

Products

LUM-A/B/C corrugated board production line is a process of corrugating, gluing, drying, cooling and shaping, slitting and creasing, cross-cutting into standard board, and finally conveying and stacking to produce qualified board products, realizing high-speed and efficient assembly line operation. The company produces high-, medium- and low-grade 3, 5, and 7-layer corrugated board production lines with production widths ranging from 1400 to 2800mm and production speeds ranging from 60m to 250m/min, which can be selected by users according to their needs.

Main characteristics：

  1. The material is made of high-quality chromium-molybdenum alloy steel or tungsten carbide.
  2. The corrugated shape is the internationally accepted UV type, carefully designed, with low paper shrinkage, and the pressed paperboard is of good quality and high strength.
  3. Using imported precision machine tools, advanced forming grinding and computer indexing technology, the flute size accuracy meets national standards.
Get a Quate
Model number Model MY-1200 MY-1300 MY-1500 MY-1600
Maximum paper feed size ( mm ) Max paper size 1230*850mm 1320*940mm 1510*1120mm 1620*1250mm
Minimum paper feed size( mm ) Min paper size 350*450mm 400*500mm 400*550mm 500*550mm
Maximum die cutting size( mm ) Max die-cutting size 1210*830mm 1300*920mm 1490*1100mm 1600*1220mm
Minimum mouth size( mm ) Min size in mouth 6mm 6mm 6mm 6mm
Maximum die cutting pressure( T ) Max die cutting pressure 300N/cm² 300N/cm² 300N/cm² 300N/cm²
Machinable paper( mm ) Cardboard 200-2000 g/ m² 200-2000 g/ m² 200-2000 g/ m² 200-2000 g/ m² 200-2000 g/ m²
Corrugated board 8mm (max thickness) 8mm (max thickness) 8mm (max thickness) 8mm (max thickness) 8mm (max thickness)
Die cutting accuracy( mm ) Die cutting precision ±0.1mm ±0.1mm ±0.1mm ±0.1mm
Maximum speed(sheets/hour) Max die cutting speed 4500 sheets/h 4500 sheets/h 4500 sheets/h 4500 sheets/h
Maximum stack height
of paper feed(mm)		 Max feeding pile height 1400mm
(above the level)		 1400mm
(above the level)		 1400mm
 (above the level)		 1400mm
 (above the level)
Minimum stack height
for receiving paper(mm)		 Min delivery pile height 1200mm
(above the level)		 1250mm
(above the level)		 1250mm
 (above the level)		 1300mm
(above the level)
Gross power(KW) Total power 11.0kw 13.5kw 13.5kw 15.0kw
Machine weight(T) Total weight 13.0 T 14.5 T 17.5 T 20.0 T
Overall dimension Overall dimension 4200x2200x2250mm 4200x2250x2250mm 4200x2300x2250mm 5200x2450x2250mm
